OCP500 series beamsplitter cube
1. Material: K9 optical glass
2. Dimension Tolerance: ±0.2mm
3. Clear Aperture: >90%
4. Flatness: λ/[email protected]
5. Beam Deviation: <3 arc minutes
6. Surface Quality: 60/40
7. Coating: Partial reflectance on hypotenuse face,AR coating on all entrances
8. Damage Threshold: >500mJ/cm2, 20ns, 20Hz, @1064nm
9. T/R: 50/50±5%, T=(Ts+Tp)/2, R=(Rs+Rp)/2
- description
- parameters
|
Model |
Size(mm) |
T/R |
Wavelength(nm) |
Polarization |
|
OCP501 |
5.0×5.0×5.0 |
50:50±5% |
450 - 650 |
Avg |
|
OCP502 |
10.0×10.0×10.0 |
50:50±5% |
450 - 650 |
Avg |
|
OCP503 |
12.7×12.7×12.7 |
50:50±5% |
450 - 650 |
Avg |
|
OCP504 |
15.0×15.0×15.0 |
50:50±5% |
450 - 650 |
Avg |
|
OCP505 |
20.0×20.0×20.0 |
50:50±5% |
450 - 650 |
Avg |
|
OCP506 |
25.4×25.4×25.4 |
50:50±5% |
450 - 650 |
Avg |
|
OCP507 |
5.0×5.0×5.0 |
50:50±5% |
650 - 900 |
Avg |
|
OCP508 |
10.0×10.0×10.0 |
50:50±5% |
650 - 900 |
Avg |
|
OCP509 |
12.7×12.7×12.7 |
50:50±5% |
650 - 900 |
Avg |
|
OCP510 |
15.0×15.0×15.0 |
50:50±5% |
650 - 900 |
Avg |
|
OCP511 |
20.0×20.0×20.0 |
50:50±5% |
650 - 900 |
Avg |
|
OCP512 |
25.4×25.4×25.4 |
50:50±5% |
650 - 900 |
Avg |
|
OCP513 |
5.0×5.0×5.0 |
50:50±5% |
900 - 1200 |
Avg |
|
OCP514 |
10.0×10.0×10.0 |
50:50±5% |
900 - 1200 |
Avg |
|
OCP515 |
12.7×12.7×12.7 |
50:50±5% |
900 - 1200 |
Avg |
|
OCP516 |
15.0×15.0×15.0 |
50:50±5% |
900 - 1200 |
Avg |
|
OCP517 |
20.0×20.0×20.0 |
50:50±5% |
900 - 1200 |
Avg |
|
OCP518 |
25.4×25.4×25.4 |
50:50±5% |
900 - 1200 |
Avg |
